A red X indicates that a problem exists or the connection is down. For a WiFi
network, the network is disabled or down.
•
An amber exclamation mark indicates that the AP cannot get an Internet connection
(for example, because a cable is disconnected), that a WiFi network is enabled but
open (that is, it is unprotected), or that another situation that requires your attention
occurred.
Note: By default, the AP’s WiFi network in the 2.4 GHz and 5 GHz bands is open
and unsecured. We recommend that you set up WiFi security for both radio bands.
The following table describes the fields of the four panes on the Home page.
DescriptionField
AP Information
The AP name. By default, the name is WAC104. For more information, see
Manage the basic WiFi settings and WiFi security of the WiFi network on page
33.
AP Name
The Media Access Control (MAC) address of Ethernet (LAN) interface through
which the AP connects to the router or network switch or hub. This address
does not change.
Ethernet MAC Address
The MAC address of the 2.4 GHz radio. This address is also the basic service
set identifier (BSSID) of the 2.4 GHz radio. This address does not change.
Wireless MAC Address for
2.4 GHz
The MAC address of the 5 GHz radio. This address is also the BSSID of the 5
GHz radio. This address does not change.
Wireless MAC Address for 5
GHz
The country and region in which the AP is being used. For more information,
see see Manage the basic WiFi settings and WiFi security of the WiFi network
on page 33.
Region
The version of the AP firmware. If you upgrade the firmware on the AP, the
version changes. For more information, see Update the firmware of the AP on
page 47.
Firmware Version
The serial number of the AP. This number does not change.Serial Number
The current date and time. For more information, see Set the time zone and
adjust the daylight saving time on page 28.
Current Time
The time elapsed since the AP was last restarted.
The up time ignores restarting of the local browser UI, which occurs when you
save the settings for certain features. (To keep things simple, restarting the
local browser UI is often referred to as restarting the AP, but it is not the same.)
Up Time
IP Settings
The IP address settings that the AP uses. In almost all situations, these IP address settings are assigned by
your router or a DHCP server in your network.
For information about how to configure the Internet settings, see Connect and log in to the AP for initial
configuration on page 19 or Change the IP address settings of the AP on page 57.
User Manual62Manage the AP and Monitor the
Traffic
802.11ac Wireless Access Point Model WAC104
