NETGEAR WAC104 User Manual

To connect the AP to a router (or switch or hub that is connected to a DHCP server):
1.
Connect the Ethernet cable that came in the package to one of the AP’s Ethernet
ports.
You can use any of the four LAN ports on the AP.
2.
Connect the other end of the cable to a LAN port on your router (or switch or hub
that is connected to a DHCP server).
3. Power on the AP.
The Power LED lights solid green. If the Power LED does not light, press the Power
On/Off button.
Wait for the WiFi LED to light solid green. If the WiFi LED does not light, press the
WiFi On/Off button.
4.
Log in to the AP by using one of the methods that are described in Connect and log
in to the AP for initial configuration on page 19.
About logging in to the local browser UI
IMPORTANT: The steps to log in to the local browser user interface (UI) of your AP
depend on the firmware version that your AP is running.
The steps in this manual apply only if you update your AP firmware to version 1.0.4.15
or a later version and then reset the AP to factory defaults. If you already reset the AP
to factory defaults after you updated to version 1.0.4.15, and you update the AP to a
version later than 1.0.4.15, you do not need to reset the AP to factory defaults again.
If your AP is running a firmware version earlier than version 1.0.4.15 and you do not
update to version 1.0.4.15 or a later version, see the old user manual, which you can
download by visiting netgear.com/support/download/.
IMPORTANT: We strongly recommend that you download and install the latest firmware
as soon as possible.
User Manual18Install and Access the AP in Your
Network
802.11ac Wireless Access Point Model WAC104

NETGEAR WAC104 Specifications

General

Ethernet WAN	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
Number of WLAN connections (max)	128
WLAN data transfer rate (first band)	300 Mbit/s
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Antennas quantity	3
Security algorithms	WEP, WPA-PSK, WPA2-PSK
Power source type	AC
Power consumption (typical)	8.1 W
Product type	Tabletop router
Product color	Black
LED indicators	LAN, WPS
USB port	No
Ethernet LAN (RJ-45) ports	4
Storage temperature (T-T)	-120 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE (EN60950)
Mean time between failures (MTBF)	285000 h
Cables included	LAN (RJ-45)
Package depth	192 mm
Package width	247 mm
Package height	98 mm
Package weight	780 g
Harmonized System (HS) code	85176990
Shipping (inner) case width	507 mm
Shipping (inner) case height	270 mm
Shipping (inner) case length	399 mm
Shipping (inner) case net weight	8620 g
Number of layers per pallet (sea)	7 pc(s)
Number of cartons per pallet layer	5 pc(s)
Quantity per shipping (inner) case	10 pc(s)

Weight and Dimensions

Depth	181.45 mm
Width	239.65 mm
Height	40.6 mm
Weight	385 g
