Page #53 background imageLoading...
Page #53 background image
The Set Password page displays.
5. Enter the old password.
6. Enter the new password twice.
Note: For information about setting up password recovery, see Enable password
recovery or change the recovery questions on page 53.
7. Click the Apply button.
Your settings are saved.
Enable password recovery or change the
recovery questions
During the initial log-in process, you were prompted to set up password recovery for
the local device password (also referred to as the admin password). This is the password
that you use to log in locally to the AP with the user name admin. If you forget this
password, you can recover it. The recovery process is supported in the Chrome, Safari,
Firefox, and Internet Explorer browsers.
If you did not enable password recovery during the initial log-in process, you can enable
it. If you did enable password recovery, you change the password recovery questions.
To enable password recovery or change the password recovery questions:
1.
Connect your computer or mobile device to the AP in one of the following ways:
Connect directly to the AP’s WiFi network or LAN.
Connect to the same network that the AP is connected to.
2.
Launch a web browser and enter http://www.aplogin.net (or aplogin.net) in the
address field.
Instead, if you are connected to same network as the AP, enter the LAN IP address
that is assigned to the AP. For information about finding the IP address, see Find the
IP address of the AP when you cannot use aplogin.net on page 24.
A login window displays.
3. Enter the AP local device password.
The local device password is the one that you specified. The local device password
is case-sensitive.
The Home page displays.
User Manual53Manage the AP and Monitor the
Traffic
802.11ac Wireless Access Point Model WAC104

Table of Contents

Other manuals for NETGEAR WAC104

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR WAC104 and is the answer not in the manual?

NETGEAR WAC104 Specifications

General IconGeneral
Ethernet WAN-
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)867 Mbit/s
Number of WLAN connections (max)128
WLAN data transfer rate (first band)300 Mbit/s
Ethernet LANYes
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Antennas quantity3
Security algorithmsWEP, WPA-PSK, WPA2-PSK
Power source typeAC
Power consumption (typical)8.1 W
Product typeTabletop router
Product colorBlack
LED indicatorsLAN, WPS
USB portNo
Ethernet LAN (RJ-45) ports4
Storage temperature (T-T)-120 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)10 - 90 %
CertificationCE (EN60950)
Mean time between failures (MTBF)285000 h
Cables includedLAN (RJ-45)
Package depth192 mm
Package width247 mm
Package height98 mm
Package weight780 g
Harmonized System (HS) code85176990
Shipping (inner) case width507 mm
Shipping (inner) case height270 mm
Shipping (inner) case length399 mm
Shipping (inner) case net weight8620 g
Number of layers per pallet (sea)7 pc(s)
Number of cartons per pallet layer5 pc(s)
Quantity per shipping (inner) case10 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth181.45 mm
Width239.65 mm
Height40.6 mm
Weight385 g
