4.
Launch a web browser and enter http://www.aplogin.net (or aplogin.net) in
the address field.
Instead, if you are connected to same network as the AP, enter the LAN IP address
that is assigned to the AP. For information about finding the IP address, see Find
the IP address of the AP when you cannot use aplogin.net on page 24.
A login window displays.
5.
Log in to the local browser UI with the user name is admin and the default
password password.
Changes are not saved
If you are logged in to the AP local browser UI and the AP does not save the changes
that you make on a page, do the following:
•
When entering configuration settings, always click the Apply button before moving
to another page or tab or your changes are lost.
•
Click the Refresh or Reload button in the web browser. It is possible that the changes
occurred but that the old settings remain in the web browser’s cache.
Troubleshoot your network using the ping
utility
Most network devices and routers contain a ping utility that sends an echo request
packet to the designated device. The device then responds with an echo reply. You can
easily troubleshoot a network using the ping utility in your computer or workstation.
Test the LAN path to your AP
You can ping the AP from your computer to verify that the LAN path to your AP is set
up correctly.
To ping the AP from a Windows computer:
1. From the Windows taskbar, click the Start button and select Run.
2.
In the field provided, enter ping followed by the IP address of the AP, as in this
example:
ping 192.168.0.100
3. Click the OK button.
User Manual89Troubleshooting
802.11ac Wireless Access Point Model WAC104
