NETGEAR WAC104 User Manual

View information about the AP and the IP and WiFi settings
You can view information about the AP and the IP and WiFi settings for each of the
radios.
To view information about the AP and the IP and WiFi settings:
1.
Connect your computer or mobile device to the AP in one of the following ways:
•
Connect directly to the AP’s WiFi network or LAN.
•
Connect to the same network that the AP is connected to.
2.
Launch a web browser and enter http://www.aplogin.net (or aplogin.net) in the
address field.
Instead, if you are connected to same network as the AP, enter the LAN IP address
that is assigned to the AP. For information about finding the IP address, see Find the
IP address of the AP when you cannot use aplogin.net on page 24.
A login window displays.
3. Enter the AP local device password.
The local device password is the one that you specified. The local device password
is case-sensitive.
The Home page displays.
The information onscreen uses the following color coding:
•
A green flag indicates that the AP information and IP settings are fine and no
problems exist. For a WiFi network, the network is enabled and secured.
User Manual61Manage the AP and Monitor the
Traffic
802.11ac Wireless Access Point Model WAC104

NETGEAR WAC104 Specifications

General

Ethernet WAN	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
Number of WLAN connections (max)	128
WLAN data transfer rate (first band)	300 Mbit/s
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Antennas quantity	3
Security algorithms	WEP, WPA-PSK, WPA2-PSK
Power source type	AC
Power consumption (typical)	8.1 W
Product type	Tabletop router
Product color	Black
LED indicators	LAN, WPS
USB port	No
Ethernet LAN (RJ-45) ports	4
Storage temperature (T-T)	-120 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE (EN60950)
Mean time between failures (MTBF)	285000 h
Cables included	LAN (RJ-45)
Package depth	192 mm
Package width	247 mm
Package height	98 mm
Package weight	780 g
Harmonized System (HS) code	85176990
Shipping (inner) case width	507 mm
Shipping (inner) case height	270 mm
Shipping (inner) case length	399 mm
Shipping (inner) case net weight	8620 g
Number of layers per pallet (sea)	7 pc(s)
Number of cartons per pallet layer	5 pc(s)
Quantity per shipping (inner) case	10 pc(s)

Weight and Dimensions

Depth	181.45 mm
Width	239.65 mm
Height	40.6 mm
Weight	385 g
