NETGEAR WAC104 User Manual

DescriptionField
Wired Devices
For LAN devices, the status is always Allowed.Status
The device name, if detected.Device Name
The IP address that is assigned to the device when it joined the network. This address can
change when a device is disconnected and rejoins the network.
IP Address
The unique MAC address. The MAC address does not change and is usually shown on the
product label.
MAC Address
For LAN devices, the connection type is always Wired.Connection
Type
Wireless Devices
If access control is enabled (see Manage access to the WiFi network through a WiFi access
list on page 71), the access control status of the device in the network (Allowed or Blocked).
Status
The device name, if detected.Device Name
The basic service set identifier (BSSID), which is the MAC address of the radio to which the
WiFi device is connected.
BSSID
The service set identifier (SSID) or WiFi network name that the WiFi device is using.SSID
The type of WiFi security, if any, for the WiFi network to which the device is connected.Type
The radio to which the WiFi device is connected (2.4 GHz or 5 GHz).Radio
The unique MAC address. The MAC address does not change and is usually shown on the
product label.
MAC Address
For WiFi devices, the connection type is always Wireless.Connection
Type
5.
To refresh the information onscreen, click the Refresh button.
The information onscreen is updated.
View the status and statistics of the AP
You can view information about the AP, its IP settings, and its WiFi network. In addition,
you can view traffic statistics for the various ports.
User Manual60Manage the AP and Monitor the
Traffic
802.11ac Wireless Access Point Model WAC104

NETGEAR WAC104 Specifications

General

Ethernet WAN	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
Number of WLAN connections (max)	128
WLAN data transfer rate (first band)	300 Mbit/s
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Antennas quantity	3
Security algorithms	WEP, WPA-PSK, WPA2-PSK
Power source type	AC
Power consumption (typical)	8.1 W
Product type	Tabletop router
Product color	Black
LED indicators	LAN, WPS
USB port	No
Ethernet LAN (RJ-45) ports	4
Storage temperature (T-T)	-120 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE (EN60950)
Mean time between failures (MTBF)	285000 h
Cables included	LAN (RJ-45)
Package depth	192 mm
Package width	247 mm
Package height	98 mm
Package weight	780 g
Harmonized System (HS) code	85176990
Shipping (inner) case width	507 mm
Shipping (inner) case height	270 mm
Shipping (inner) case length	399 mm
Shipping (inner) case net weight	8620 g
Number of layers per pallet (sea)	7 pc(s)
Number of cartons per pallet layer	5 pc(s)
Quantity per shipping (inner) case	10 pc(s)

Weight and Dimensions

Depth	181.45 mm
Width	239.65 mm
Height	40.6 mm
Weight	385 g
