NETGEAR WAX214v2 User Manual

Figure 1. Top panel with LEDs
Table 1. LED descriptions
DescriptionLED Icon
Solid amber: The AP is starting. If the LED remains solid amber, the PoE power is not
at the required 802.3at (PoE+) level.
Power LED
Blinking amber: The firmware is being updated, or the AP cannot detect a DHCP server.
Solid green: The AP is powered on and ready.
Off: No power is supplied to the AP.
Solid green: The LAN/PoE+ port detects a 1 Gbps link with a powered-on device.LAN LED
Blinking green: The LAN/PoE+ port is processing traffic at 1 Gbps speed.
Solid amber: The LAN/PoE+ port detects a 100 Mbps or 10 Mbps link with a powered-on
device.
Blinking amber: The LAN/PoE+ port is processing traffic at 100 Mbps or 10 Mbps
speed.
Off: Either no powered-on Ethernet device is connected to the LAN/PoE+ port, or, if a
powered-on Ethernet device is connected, no Ethernet link is detected.
User Manual9Hardware Overview Model
WAX214v2
Essentials WiFi 6 AX1800 Dual Band Access Point Model WAX214v2

NETGEAR WAX214v2 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1201 Mbit/s
Maximum data transfer rate (2.4 GHz)	573.5 Mbit/s
Placement	Ceiling, Wall
Product color	White
Security algorithms	SSID, WPA2, WPA3
Number of SSID supported	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Antenna type	Internal
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Width	196 mm
Height	44.4 mm
Weight	523 g
