Table 1. LED descriptions (Continued)
DescriptionLED Icon
Solid green: The 2.4 GHz radio is operating without clients.2.4 GHz
WLAN LED
Solid blue: The 2.4 GHz radio is operating with clients.
Blinking blue: The 2.4 GHz radio is transmitting or receiving data.
Off: The 2.4 GHz WiFi radio is off.
Solid green: The 5 GHz radio is operating without clients.5 GHz
WLAN LED
Solid blue: The 5 GHz radio is operating with clients.
Blinking blue: The 5 GHz radio is transmitting or receiving data.
Off: The 5 GHz WiFi radio is off.
Note: For information about troubleshooting with the LEDs, see Troubleshoot with the
LEDs on page 114.
Hardware interfaces
The bottom panel of the AP has a DC power connector for the power adapter, Reset
button, and LAN/PoE+ port.
