The Dashboard page displays.
4. Select Management > System Manager > Backup Settings.
The page that displays shows the Reboot the device section and the Backup/Restore
Settings section.
5. Click the Reboot the device button.
A pop-up window displays.
6. Click the OK button.
The AP restarts. The page displays the progress.
WARNING: To avoid the risk of corrupting the firmware, do not interrupt the restart.
For example, do not close the browser, click a link, or load a new page. Do not turn
off the AP. Wait until the AP finishes.
When the restart is finished, the login page displays.
Schedule the AP to automatically restart
You can schedule the AP to automatically restart at a time that is convenient for the
network, for example, when you do not expect any WiFi traffic to be processed.
To schedule the AP to automatically restart:
1.
Launch a web browser from a computer or tablet that is directly connected over WiFi
to the AP or connected to the same network as the AP.
2. Enter the IP address that is assigned to the AP.
If you are directly connected to the management WiFi network, you can enter
https://www.aplogin.net.
A login page displays.
If you do not know the IP address, see Find the IP address of the AP on page 24. For
more information about the management WiFi network, see Management WiFi
network on page 43.
If your browser displays a security warning, you can proceed, or add an exception
for the security warning. For more information, see kb.netgear.com/000062980.
3. Enter the AP login password and click the LOGIN button.
The AP login password is the one that you specified the first time you logged in to
the AP. The password is case-sensitive.
The Dashboard page displays.
User Manual90Maintain the AP
Essentials WiFi 6 AX1800 Dual Band Access Point Model WAX214v2

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR WAX214v2 and is the answer not in the manual?

NETGEAR WAX214v2 Specifications

General IconGeneral
2.4 GHzYes
MIMO typeMulti User MIMO
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Maximum data transfer rate1201 Mbit/s
Maximum data transfer rate (2.4 GHz)573.5 Mbit/s
PlacementCeiling, Wall
Product colorWhite
Security algorithmsSSID, WPA2, WPA3
Number of SSID supported4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports1
Antenna typeInternal
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 95 %
Weight and Dimensions IconWeight and Dimensions
Width196 mm
Height44.4 mm
Weight523 g
