NETGEAR WAX214v2 User Manual

Additional documentation
The following documents are available at netgear.com/support/download/:
•
Installation guides
•
Data sheets
Unpack the AP
The package contains the following items:
•
WAX214v2 AP
•
Mounting plate with screw holes for mounting to a wall or ceiling with a 15/16 in.
(24 mm) T-bar
•
Metal bracket with T-bar lock, lock screw, and 4 short screws
Use these parts to mount the AP to celing with a T-bar.
•
2 Phillips head screws and anchors for mounting
Use these parts to mount the AP to a wall.
•
Installation guide
Note: You power up the AP by connecting it to a PoE+ switch. Depending on the
product ordered, the package might also include a power adapter. If you ordered a
package without a power adapter, you can still order a power adapter as an option.
For information about the mounting options, see Mount the AP to a Wall or Ceiling on
page 128.
Top panel with LEDs
The LEDs that provide the status of the AP are located on the top panel of the AP.
User Manual8Hardware Overview Model
WAX214v2
Essentials WiFi 6 AX1800 Dual Band Access Point Model WAX214v2

NETGEAR WAX214v2 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1201 Mbit/s
Maximum data transfer rate (2.4 GHz)	573.5 Mbit/s
Placement	Ceiling, Wall
Product color	White
Security algorithms	SSID, WPA2, WPA3
Number of SSID supported	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Antenna type	Internal
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Width	196 mm
Height	44.4 mm
Weight	523 g
