Terminal Web Interface
User Manual for the Satellite Terminal
version 3.0
14
3.6.2.2 Demodulator
The Demodulator state is indicated by a coloured LED and a state description.
LED colour code Description
Green The demodulator is locked.
Red The demodulator is not locked.
Table 9 - Status Page > Demodulator LED
The demodulator state is built as follows (see Table 10 for more details):
-95.0 dBM, Es/No: 23.2 dB, <Satellite network name>
Demodulator label value Description
y dBm
Indication of the received signal strength expressed
in dBm. This indication can change when going from
pointing mode to operational mode.
Es/No
Es/No is an indication of the received signal quality
expressed in dB. This indication can change when
going from pointing mode to operational mode.
Table 10 - Status Page > Demodulator Labels
3.6.2.3 Info by Error State
An error message can be displayed. This error message displays the current error
status and will be reset when the terminal has entered the satellite network and the
terminal is operational.
Please refer to Appendix C – Troubleshooting Guide for more
details on possible errors and actions needed to resolve the
occurring error.
3.6.2.4 Software Version
The running software version is indicated by its version number.
3.6.2.5 Pointing
This
section of the web interface displays information on the pointing status of the
terminal.
The following status can be viewed:
Status when the antenna is not pointed as shown in Figure 13, giving the option
to start pointing or to skip pointing. Where two pointing carriers are available, one
can choose the used carrier as shown in Figure 14;
Status during the pointing of the antenna; see Figure 15. Click on Pointing
