NSA 5130 User Manual
Chapter 1: Product Introduction
Hardware Specifications
NSA 5130 System
Physical Characteristics
• Form Factor
- 19” 1U
• Construction
- SECC steel plate, 1.0 mm thick
• Color
- Nexcom 295U
• Dimensions (W x D x H)
- 430 mm x 450 mm x 44 mm
• Mounting
- Mounting ear
• System chassis
- NSC5130
System Cooling
• Cooling Method
- Removable system fan at the rear of the chassis
• Cooler Type
- Four system fans with controllable fan speed
• Ventilation
- Suction from the side and discharged to the back
Main Board
• NSB 5130
• Intel
®
2nd generation Core™ processors, Max 95watt
• Intel
®
C206
• 4 x 240-pin DDR3 1066/1333MHz DIMM sockets, up to 16GB ECC/
non-ECC SDRAM
• Intel
®
82583V LAN chip, LAN Bypass: 4 pairs, 10/100/1000 link speed
I/O Interface - Front
• Console port
- 1 RJ45 type
• USB port
- 2 USB ports
• LAN port
- 8 RJ45 copper LAN ports
• Keypad (optional)
- LCM keypad
• LCD
- 2x16 characters LCD module, PIO interface (optional)
• Button
- 1 GPIO software button
• LAN module bay (optional)
- 1 LAN module bay
• LEDs
- Power Status/HDD Status/LAN Status/Bypass Status LED
I/O Interface - Rear
• 1 VGA port (optional)
• 2 USB 2.0 ports (optional)
• 1 expansion slot
Storage
• 1 onboard CompactFlash socket
• 1 internal 3.5” HDD bay or 2 2.5” HDD bay
• 1 SATA DOM device space
Expansion
• 1 x PCIe x8 slot
