NSA 5130 User Manual
Chapter 1: Product Introduction
Main Board (NSB 5130)
Processor
• CPU
- Intel
®
2nd generation Core™ processors, Max 95watt
Chipset
• Intel
®
C206
Memory
• Technology
- DDR3 1066/1333MHz ECC and Non-ECC memory
• Sockets
- Four 240-pin DDR3 DIMM sockets
• Capacity
- 16GB maximum memory
Network
• Onboard LAN controller
- Intel 82583V x8 (connected from Intel 3450 PCIe bus)
• Link speed
- 10/100/1000
• Bypass
- 4 pairs (dual latch bypass, Active Bypass status report)
• Media type
- Copper
• PXE boot
- ETH1 (the left side of LAN)
• LAN module (optional)
- One PCIe x8 connected to CPU PCIe bus
- Supports Nexcom NSK53xx series modules
Storage
• SATA
- Two SATA connectors with power connector for one 3.5” HDD (de-
fault) or two 2.5” HDD (optional)
• SATA DOM
- One SATA DOM connector with power connector (JST 2-pin)
• CompactFlash
- JMicron JMD330 SATA to IDE bridge
- One CompactFlash socket
Status Indicator
• Power LED
- Green: Lights green when the system is On.
• HDD LED
- Yellow: Lights yellow when the HDD is active.
• GPIO LED
- Yellow
• Bypass LED
- Yellow
RTC
• Controller
- Built-in controller
• Backup battery
- Lithium ion battery
