NSA 5130 User Manual
Chapter 3: System Setup
Installing a CompactFlash Card
2. With the CompactFlash card’s label facing up, position the card to the
socket.
CompactFlash
socket
CompactFlash
card
1. Locate for the CompactFlash socket on the board.
