NSA 5130 User Manual
Chapter 2: Jumpers and Connectors
SATA DOM Power Connector
Connector type: 1x2 2-pin boxed header, 2.5 mm JST
Connector location: J13
1 2
Pin Definition
1 VCC5
2 GND
Digital I/O Connector (4 Input, 4 Output)
Connector type: 2x5 10-pin header, 2.0 mm
Connector location: J9
10
9
2
1
Pin Definition Pin Definition
1 VCC5 2 GND
3 SIO_GP32 4 SIO_GP06
5 SIO_GP03 6 SIO_GP07
7 SIO_GP04 8 SIO_GP76
9 SIO_GP05 10 SIO_GP77
