NSA 5130 User Manual
Chapter 2: Jumpers and Connectors
PCIe Gold Finger (for LAN Module)
Connector type: 2x49-pin
Connector location: GFM1
Pin Definition Pin Definition
A1 PLT_RST_BUF3_N B1 PCIE3_SEL1
A2 LPC_AD0 B2 PCIE3_SEL2
A3 LPC_AD1 B3 PCIE3_SEL3
A4 LPC_AD2 B4 VCC3_3
A5 LPC_AD3 B5 SMB_CLK_MAIN
A6 LPC_FRAME_N B6 SMB_DATA_MAIN
A7 VCC3_3 B7 VCC3_3
A8 PLT_RST_BUF3_N B8 VCC3_3
A9 VCC3_3 B9 GF_SUSCLK
A10 VCC3_3 B10 VCC3_3
A11 PCH_PWROK B11 SMB_ALERT_N
A12 SYS_FAN B12 USB_OC2_N
A13 VCC3_3 B13 WAKE_N
A14 VCC3_3 B14 3VSB
A15 PCIE_X8_GF_CLK_P B15 3VSB
A16 PCIE_X8_GF_CLK_N B16 3VSB
A17 VCC3_3 B17 USB_4P
A18 CLK_GF_33M B18 USB_4N
A19 VCC3_3 B19 VCC3_3
A20 AUX_TEMP B20 VCC3_3
Pin Definition Pin Definition
A21 CPU- B21 VCC3_3
A22 ATX_PWROK4 B22 ATX_PWROK5
A23 ATX_PWROK4 B23 ATX_PWROK5
A24 GND B24 GND
A25 PCIEX8_TX0P B25 PCIEX8_RX0P
A26 PCIEX8_TX0N B26 PCIEX8_RX0N
A27 GND B27 GND
A28 PCIEX8_TX1P B28 PCIEX8_RX1P
A29 PCIEX8_TX1N B29 PCIEX8_RX1N
A30 GND B30 GND
A31 PCIEX8_TX2P B31 PCIEX8_RX2P
A32 PCIEX8_TX2N B32 PCIEX8_RX2N
A33 GND B33 GND
A34 PCIEX8_TX3P B34 PCIEX8_RX3P
A35 PCIEX8_TX3N B35 PCIEX8_RX3N
A36 GND B36 GND
A37 PCIEX8_TX4P B37 PCIEX8_RX4P
A38 PCIEX8_TX4N B38 PCIEX8_RX4N
A39 GND B39 GND
A40 PCIEX8_TX5P B40 PCIEX8_RX5P
A41 PCIEX8_TX5N B41 PCIEX8_RX5N
A42 GND B42 GND
A43 PCIEX8_TX6P B43 PCIEX8_RX6P
To Next Page
