NSA 5130 User Manual
Chapter 2: Jumpers and Connectors
Pin Definition Pin Definition
A44 PEG_SLOT_RX9N B44 GND
A45 GND B45 PEG_SLOT_TX8P
A46 GND B46 PEG_SLOT_TX8N
A47 PEG_SLOT_RX8P B47 GND
A48 PEG_SLOT_RX8N B48 PCIE16_PRSNT2_3
A49 GND B49 GND
A50 B50 PEG_SLOT_TX7P
A51 GND B51 PEG_SLOT_TX7N
A52 PEG_SLOT_RX7P B52 GND
A53 PEG_SLOT_RX7N B53 GND
A54 GND B54 PEG_SLOT_TX6P
A55 GND B55 PEG_SLOT_TX6N
A56 PEG_SLOT_RX6P B56 GND
A57 PEG_SLOT_RX6N B57 GND
A58 GND B58 PEG_SLOT_TX5P
A59 GND B59 PEG_SLOT_TX5N
A60 PEG_SLOT_RX5P B60 GND
A61 PEG_SLOT_RX5N B61 GND
A62 GND B62 PEG_SLOT_TX4P
A63 GND B63 PEG_SLOT_TX4N
A64 PEG_SLOT_RX4P B64 GND
A65 PEG_SLOT_RX4N B65 GND
A66 GND B66 PEG_SLOT_TX3P
A67 GND B67 PEG_SLOT_TX3N
A68 PEG_SLOT_RX3P B68 GND
Pin Definition Pin Definition
A69 PEG_SLOT_RX3N B69 GND
A70 GND B70 PEG_SLOT_TX2P
A71 GND B71 PEG_SLOT_TX2N
A72 PEG_SLOT_RX2P B72 GND
A73 PEG_SLOT_RX2N B73 GND
A74 GND B74 PEG_SLOT_TX1P
A75 GND B75 PEG_SLOT_TX1N
A76 PEG_SLOT_RX1P B76 GND
A77 PEG_SLOT_RX1N B77 GND
A78 GND B78 PEG_SLOT_TX0P
A79 GND B79 PEG_SLOT_TX0N
A80 PEG_SLOT_RX0P B80 GND
A81 PEG_SLOT_RX0N B81 PCIE_X16_CLK_2P
A82 GND B82 PCIE_X16_CLK_2N
To Next Page
