NSA 5130 User Manual
Chapter 2: Jumpers and Connectors
PCIe Slot
Connector type: 2x82-pin PCIe x8 slot
Connector location: PCIE1
Pin Definition Pin Definition
A1 PCIE16_PRSNT1 B1 VCC12
A2 VCC12 B2 VCC12
A3 VCC12 B3 VCC12
A4 GND B4 GND
A5 VCC3_3 B5 PCIE16_SMC
A6 VCC3_3 B6 PCIE16_SMD
A7 VCC3_3 B7 GND
A8 VCC3_3 B8 VCC3_3
A9 VCC3_3 B9 VCC12
A10 VCC3_3 B10 3VSB
A11 PLT_RST_BUF3_N B11 PCIE_WAKE_L
A12 GND B12 VCC12
A13 PCIE_X16_CLK_1P B13 GND
A14 PCIE_X16_CLK_1N B14 PEG_SLOT_TX15P
A15 GND B15 PEG_SLOT_TX15N
A16 PEG_SLOT_RX15P B16 GND
A17 PEG_SLOT_RX15N B17 PCIE16_PRSNT2_1
A18 GND B18 GND
Pin Definition Pin Definition
A19 VCC12 B19 PEG_SLOT_TX14P
A20 GND B20 PEG_SLOT_TX14N
A21 PEG_SLOT_RX14P B21 GND
A22 PEG_SLOT_RX14N B22 GND
A23 GND B23 PEG_SLOT_TX13P
A24 GND B24 PEG_SLOT_TX13N
A25 PEG_SLOT_RX13P B25 GND
A26 PEG_SLOT_RX13N B26 GND
A27 GND B27 PEG_SLOT_TX12P
A28 GND B28 PEG_SLOT_TX12N
A29 PEG_SLOT_RX12P B29 GND
A30 PEG_SLOT_RX12N B30 VCC12
A31 GND B31 PCIE16_PRSNT2_2
A32 VCC12 B32 GND
A33 VCC12 B33 PEG_SLOT_TX11P
A34 GND B34 PEG_SLOT_TX11N
A35 PEG_SLOT_RX11P B35 GND
A36 PEG_SLOT_RX11N B36 GND
A37 GND B37 PEG_SLOT_TX10P
A38 GND B38 PEG_SLOT_TX10N
A39 PEG_SLOT_RX10P B39 GND
A40 PEG_SLOT_RX10N B40 GND
A41 GND B41 PEG_SLOT_TX9P
A42 GND B42 PEG_SLOT_TX9N
A43 PEG_SLOT_RX9P B43 GND
