NSA 5130 User Manual
Chapter 2: Jumpers and Connectors
Jumpers
CMOS Clear
Connector type: 1x3 3-pin header, 2.54 mm pitch
Connector location: JP5
1
3
Pin Settings
1-2 On Normal
2-3 On CMOS Clear
1-2 On: default
Pin Definition
1 NC
2 ICH_RTCRST_N
3 Battery GND
ME Force Update
Connector type: 1x3 3-pin header, 2.54 mm pitch
Connector location: JP3
1
3
Pin Settings
1-2 On Normal
2-3 On ME Force Update
1-2 On: default
Pin Definition
1 NC
2 GPIO24
3 GND
