NSA 5130 User Manual
Chapter 2: Jumpers and Connectors
Power Connector
Connector type: 2x10 20-pin header
Connector location: CN6
1
11
10
20
Pin Definition Pin Definition
1 VCC3_3 2 VCC3_3
3 GND 4 VCC5
5 GND 6 VCC5
7 GND 8 ATXPWROK
9 5VSB 10 VCC12
11 VCC3_3 12 NC
13 GND 14 SIO_PSON_N
15 GND 16 GND
17 GND 18 NC
19 VCC5 20 VCC5
GAL Programming Connector
Connector type: 1x6 6-pin header, 2.54 mm
Connector location: J10
6
1
Pin Definition
1 3VSB
2 GND
3 GAL_TCK
4 GAL_TDO
5 GAL_TDI
6 GAL_TMS
