NSA 5130 User Manual
Chapter 2: Jumpers and Connectors
HW Reset Button
Connector type: 1x2 2-pin header, 2.54 mm pitch
Connector location: JP6
1
2
Pin Definition
1 PCH_SYS_RESET_N_R
2 GND
Power Button
Connector type: 1x2 2-pin header, 2.54 mm pitch
Connector location: J18
1
2
Pin Definition
1 GND
2 PCH_PWRBTN_N
