NSA 5130 User Manual
Chapter 2: Jumpers and Connectors
Internal Connectors
SATA2 Port
Connector type: Standard Serial ATAII, 1.27mm
Connector location: J12
Pin Definition
1 GND
2 SATA_TX2P
3 SATA_TX2N
4 GND
5 SATA_RX2N
6 SATA_RX2P
7 GND
1
7
SATA3 Port
Connector type: Standard Serial ATAII, 1.27mm
Connector location: J11
Pin Definition
1 GND
2 SATA_TX1P
3 SATA_TX1N
4 GND
5 SATA_RX1N
6 SATA_RX1P
7 GND
1
7
