NSA 5130 User Manual
Chapter 2: Jumpers and Connectors
LAN7 Port
Connector type: RJ45 port with LEDs
Connector location: CON2C
Act
Link
Act Status
Green
Blinking
Data Activity
Off No Acitivity
Pin Definition Pin Definition
A1 LAN7_TXP0_CON A2 LAN7_TXN0_CON
A3 LAN7_TXP1_CON A4 LAN7_TXP2_CON
A5 LAN7_TXN2_CON A6 LAN7_TXN1_CON
A7 LAN7_TXP3_CON A8 LAN7_TXN3_CON
A9 LAN7_LED_LINK100# A10 LAN7_LED_LINK1G#
A11 LAN7_LED_ACT# A12 LAN1_ACTPW
MH1 GND_IO
LAN8 Port
Connector type: RJ45 port with LEDs
Connector location: CON2D
Act
Link
Act Status
Green
Blinking
Data Activity
Off No Acitivity
Pin Definition Pin Definition
A1 LAN8_TXP0_CON A2 LAN8_TXN0_CON
A3 LAN8_TXP1_CON A4 LAN8_TXP2_CON
A5 LAN8_TXN2_CON A6 LAN8_TXN1_CON
A7 LAN8_TXP3_CON A8 LAN8_TXN3_CON
A9 LAN8_LED_LINK100# A10 LAN8_LED_LINK1G#
A11 LAN8_LED_ACT# A12 LAN8_ACTPW
MH1 GND_IO
