NSA 5130 User Manual
Chapter 2: Jumpers and Connectors
External I/O Interface
Connector Pin Definitions
Status Indicators
Connector location: LED9
Status LED Color
PWR Green
HDD Yellow
F6 0 Yellow
F6 1 Yellow
GPIO (F6 bit1)
GPIO (F6 bit0)
PWR
HDD
USB Ports
Connector type: Dual USB port
Connector location: CN1
Pin Definition Pin Definition
1 VCC 5 VCC
2 USB0- 6 USB1-
3 USB0+ 7 USB1+
4 GND 8 GND
