NSA 5130 User Manual
Chapter 2: Jumpers and Connectors
Console Type Select
Connector type: 1x3 3-pin header, 2.54 mm pitch
Connector location: JP1
1
3
Pin Settings
1-2 On RTS to CTS
2-3 On Normal
1-2 On: default
Pin Definition
1 SP_RTS1_R
2 SP_CTS1_R
3 SP_CTS1_CON
Power Type Select
Connector type: 1x3 3-pin header, 2.54 mm pitch
Connector location: JP4
1
3
Pin Definition
1-2 On ATX
2-3 On AT
2-3 On: default
Pin Definition
1 3VSB
2 AT_ATX_SELECT
3 GND
