NSA 5130 User Manual
Chapter 2: Jumpers and Connectors
COM2 Connector
Connector type: 2x5 10-pin boxed header, 2.0 mm
Connector location: CN3
1
2
9
10
Pin Definition Pin Definition
1 SP_DCD2 2 SP_RXD2
3 SP_TXD2 4 SP_DTR2
5 COM2_GND 6 SP_DSR2
7 SP_RTS2 8 SP_CTS2
9 SP_RI2 10 COM2_GND
USB Connector
Connector type: 1x6 6-pin, 2.0 mm JST
Connector location: J16
1
6
Pin Definition
1 VCC
2 USB2-
3 USB2+
4 USB3-
5 USB3+
6 GND
