NSA 5130 User Manual

Chapter 3: System Setup

3. Note how the module is keyed to the socket. Grasping the module by

its edges, align the module with the socket so that the “notch” on the

module is aligned with the “key” on the socket. The key ensures the

module can be plugged into the socket in only one direction.

4. Seat the module vertically, pressing it down firmly until it is completely

seated in the socket. The ejector tabs at the ends of the socket will au-

tomatically snap into the locked position to hold the module in place.
