NSA 5130 User Manual
Chapter 3: System Setup
3. Unlock the socket by pushing the load lever down (1), moving it side-
ways (2) until it is released from the retention tab; then lift the load
lever up.
Load plate
Load lever
4. Lifting the load lever will at the same time lift the load plate.
Lift the load lever up to the angle shown on the photo.
Retention tab
Load lever
1
2
