Chapter 3: System Setup
Mounting screw
5. Connect the SATA power cable and SATA data cable to the SATA drive. 6. Place the drive into the chassis and then use the provided mounting
screws to secure the drive bay in place.
SATA data
cable
SATA power
cable
