NSA 5130 User Manual
Chapter 3: System Setup
3. Align the PCI Express card with the PCI Express x8 slot and then push it
down firmly until it is completely seated in the slot.
Secure the card with the mounting screw you removed in step 2.
PCI Express
card
Mounting screw
PCI Express x8
slot
