NSA 5130 User Manual
Chapter 4: BIOS Setup
SATA Configuration
This section is used to configure SATA.
(1) IDE Mode
(2) AHCI Mode
(3) RAID Mode
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
SATA Conguration
SATA Mode
Serial-ATA Controller 0
Serial-ATA Controller 1
SATA Port0
SATA Port1
SATA Port2
SATA Port3
SATA Port4
SATA Port5
[IDE Mode]
[Compatible]
[Enhanced]
Not Preesent
ST3160813AS
Not Preesent
Not Preesent
Not Preesent
Not Preesent
u
u
SATA Mode
IDE This option configures the Serial ATA drives in IDE mode.
RAID This option enables the RAID function for Serial ATA drives.
AHCI This option configures the Serial ATA drives in AHCI mode.
Aptio Setup Utility - Copyright (C) 2008 American Megatrends, Inc.
Advanced
→ ←: Select Screen
↑↓: Select Item
Enter: Select
+
-:
Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save
ESC: Exit
Serial-ATA Controller 0 / Serial-ATA Controller 1
Configures the Serial ATA controller to Compatible or Enhanced mode.
