Nexus 1250 - Page 53

Doc# E107706 3 - 3
3: Hardware Installation
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
Figure 3.3: Legacy P40N and P40N+ Dimensions
P40N Front Dimensions
4.38” Sq.
(11.12 cm)
1.438” Sq.
(3.65 cm)
.75”
(1.91
cm)
P40N Side Dimensions
P40N+ Display
NOTE: The P40N is not intended
for new applications.
