8.6 Menu G: Profile
Menu G Profile allows the user to setup the Elevator system profile along with additional control functions
Parameter
Range(
Ú) Default(Ö)
Type
Open-Loop RFC-A RFC-S Open-Loop RFC-A RFC-S
G01 V1 Speed Reference 0 to VM_EX00_NOMINAL_ELEVATOR_SPEED mm/s 50 mm/s RW Num US
G02 V2 Speed Reference 0 to VM_EX00_NOMINAL_ELEVATOR_SPEED mm/s 400 mm/s RW Num US
G03 V3 Speed Reference 0 to VM_EX00_NOMINAL_ELEVATOR_SPEED mm/s 600 mm/s RW Num US
G04 V4 Speed Reference 0 to VM_EX00_NOMINAL_ELEVATOR_SPEED mm/s 10 mm/s RW Num US
G05 V5 Speed Reference 0 to VM_EX00_NOMINAL_ELEVATOR_SPEED mm/s 100 mm/s RW Num US
G06 V6 Speed Reference 0 to VM_EX00_NOMINAL_ELEVATOR_SPEED mm/s 100 mm/s RW Num US
G07 V7 Speed Reference 0 to VM_EX00_NOMINAL_ELEVATOR_SPEED mm/s 100 mm/s RW Num US
G08 V8 Speed Reference 0 to VM_EX00_NOMINAL_ELEVATOR_SPEED mm/s 100 mm/s RW Num US
G09 V9 Speed Reference 0 to VM_EX00_NOMINAL_ELEVATOR_SPEED mm/s 100 mm/s RW Num US
G10 V10 Speed Reference 0 to VM_EX00_NOMINAL_ELEVATOR_SPEED mm/s 100 mm/s RW Num US
G11 Acceleration Rate 0 to 10000 mm/s² 800 mm/s² RW Num US
G12 Deceleration Rate 0 to 10000 mm/s² 500 mm/s² RW Num US
G13 Run Jerk 1 1 to 65535 10mm/s³ x 10 50 mm/s³ x 10 RW Num US
G14 Run Jerk 2 1 to 65535 10mm/s³ x 10 100 mm/s³ x 10 RW Num US
G15 Run Jerk 3 1 to 65535 10mm/s³ x 10 100 mm/s³ x 10 RW Num US
G16 Run Jerk 4 1 to 65535 10mm/s³ x 10 50 mm/s³ x 10 RW Num US
G17
Creep Stop Deceleration
Rate
0 to 10000 mm/s² 1000 mm/s² RW Num US
G18 Creep Stop Jerk 1 to 65535 10mm/s³ x 10 100 mm/s³ x10 RW Num US
G19
V1 Deceleration Distance
Set point
0 to 10000 mm 0 mm RW Num US
G20
V2 Deceleration Distance
Set point
0 to 10000 mm 0 mm RW Num US
G21
V3 Deceleration Distance
Set point
0 to 10000 mm 0 mm RW Num US
G22
V4 Deceleration Distance
Set point
0 to 10000 mm 0 mm RW Num US
G23
V5 Deceleration Distance
Set point
0 to 10000 mm 0 mm RW Num US
G24
V6 Deceleration Distance
Set point
0 to 10000 mm 0 mm RW Num US
G25
V7 Deceleration Distance
Set point
0 to 10000 mm 0 mm RW Num US
G26
V8 Deceleration Distance
Set point
0 to 10000 mm 0 mm RW Num US
G27
V9 Deceleration Distance
Set point
0 to 10000 mm 0 mm RW Num US
G28
V10 Deceleration Distance
Set point
0 to 10000 mm 0 mm RW Num US
G29
Fast Stop Deceleration
Rate
0 to 10000 mm/s² 500 mm/s² RW Num US
G30
Short Floor Landing
Distance
0 to 10000 mm 0 mm RW Num US
G31
Floor Sensor Correction
Target Distance
0 to 10000 mm 0 mm RW Num US
G32
Reference Select Bit 0
Input
Off (0) or On (1) Off (0) RW Bit US
G33
Reference Select Bit 1
Input
Off (0) or On (1) Off (0) RW Bit US
G34
Reference Select Bit 2
Input
Off (0) or On (1) Off (0) RW Bit US
G35
Reference Select Bit 3
Input
Off (0) or On (1) Off (0) RW Bit US
G36
Reference Select Bit 4
Input
Off (0) or On (1) Off (0) RW Bit US
G37
Reference Select Bit 5
Input
Off (0) or On (1) Off (0) RW Bit US
G38
Reference Select Bit 6
Input
Off (0) or On (1) Off (0) RW Bit US
G39 Direction Input 1 CCW Off (0) or On (1) Off (0) RW Bit US
G40 Direction Input 2 CW Off (0) or On (1) Off (0) RW Bit US
G41 Peak Curve Enable Off (0) or On (1) Off (0) RW Bit US
G42
Peak Curve Set point
Distance
0 to 32767 mm
RO Num ND NC
