Safety
information
Product
information
Mechanical
installation
Electrical
installation
Getting
started
User Menu A Commissioning
Advanced
Parameters
Diagnostics Optimization CT MODBUS RTU Technical Data
Installation and System Design Guide 13
Issue Number: 1
2.4 Ratings
The E300 Elevator drive is configured for duty cycle operation, For constant torque applications or applications which require a high overload
capability, or full torque is required at low speeds (e.g. elevators, hoists). The thermal protection is set to protect force ventilated induction motors and
permanent magnet servo motors by default.
N
If the application uses a self ventilated (TENV/TEFC) induction motor and increased thermal protection is required for speeds below 50 % base
speed, then this can be enabled by setting Low Speed Thermal Protection Mode (B44) = On (1).
The rating label details the available output current under the following conditions:
• 40 °C (104 °F) maximum ambient,
• 1000 m altitude,
• 8 kHz switching frequency,
• A typical elevator profile (50 % ED),
• IGBT lifetime optimization enabled (reduction of switching frequency based on drive inverter temperature).
Derating is required for higher switching frequencies, ambient temperatures > 40 °C (104 °F) and higher altitude. For derating information, refer to
section 2.4.1 Power and current ratings (derating for switching frequency and temperature) on page 16.
The input current is affected by the supply voltage and impedance. The input current given on the rating label is the typical input current and is stated
for a balanced supply.
Table 2-1 200 V drive ratings
Model
Maximum input
current
Nominal output
current
Peak output current
Nom power @
230 V
Motor power @
230 V
AA AkWhp
03200106 20 10.6 18.6 2.2 3
04200137 20 13.7 24 3 3
04200185 28 18.5 32.4 4 5
05200250 31 25 43.8 5.5 7.5
06200330 48 33 57.8 7.5 10
06200440 56 44 77.0 11 15
07200610 67 61 107 15 20
07200750 84 75 132 18.5 25
07200830 105 83 146 22 30
08201160 137 116 203 30 40
08201320 166 132 231 37 50
09201760 205 176 308 45 60
09202190 260 219 383 55 75
10202830 305 283 496 75 100
10203000 361 300 525 90 125
