6.2 Parameter descriptions
Pr mm00 is available in all menus and commonly used functions are provided and can be selected as either text strings or by selecting the
appropriate numeric values as shown in the following table. For example, enter 4003 in Pr mm00 to transfer drive parameters to parameter file 003.
Table 6-3 Commonly used functions in Pr mm00
Table 6-4 Functions in Pr mm00
Pr mm00
Equivalent
value
Pr mm00 String Action
00
[No Action]
1000 1 [Save parameters] Save parameters when under voltage is not active and low voltage threshold is not active
6001 2
[Load file 1] Load the drive parameters or user program file from NV Media Card file 001
4001 3
[Save to file 1] Transfer the drive parameters to parameter file 001
6002 4
[Load file 2] Load the drive parameters or user program file from NV Media Card file 002
4002 5
[Save to file 2] Transfer the drive parameters to parameter file 002
6003 6
[Load file 3] Load the drive parameters or user program file from NV Media Card file 003
4003 7
[Save to file 3] Transfer drive parameters to parameter file 003
12000 8
[Show non-default] Displays parameters that are different from defaults
12001 9
[Destinations] Displays parameters that are set
1233 10
[Reset 50 Hz Defs] Load parameters with standard (50 Hz) defaults
1244 11
[Reset 60 Hz Defs] Load parameters with US (60 Hz) defaults
1070 12
[Reset modules] Reset all option modules
Pr mm00 Action
1000 Save parameters when Under Voltage is not active and Low Under Voltage Threshold Select mode is not active (Off (0)).
1001 Save parameter under all conditions
1070 Reset all option modules
1233 Load standard (50 Hz) defaults
1234 Load standard (50 Hz) defaults to all menus except option module menus (i.e menus P, Q and R)
1244 Load US (60 Hz) defaults
1245 Load US (60 Hz) defaults to all menus except option module menus (i.e menus P, Q and R)
1253 Change drive mode and load standard (50 Hz) defaults
1254 Change drive mode and load US (60 Hz) defaults
1255 Change drive mode and load standard (50 Hz) defaults except for menus P, Q and R
1256 Change drive mode and load US (60 Hz) defaults except for menus P, Q and R
1299 Reset {Stored HF} trip.
2001 Create a boot file on a NV Media Card based on the present drive parameters
4yyy NV Media Card: Transfer the drive parameters to parameter file xxx
6yyy NV Media Card: Load the drive parameters from parameter file xxx
7yyy NV Media Card: Erase file xxx
8yyy NV Media Card: Compare the data in the drive with file xxx
9555 NV Media Card: Clear the warning suppression flag
9666 NV Media Card: Set the warning suppression flag
9777 NV Media Card: Clear the read-only flag
9888 NV Media Card: Set the read-only flag
9999 NV Media Card: Erase and format the NV Media Card
12000 Only display parameters that are different from their default value. This action does not require a drive reset.
12001 Only display parameters that are used to set-up destinations (i.e. DE format bit is 1). This action does not require a drive reset.
15xxx Transfer the user program in an option module installed in slot 1 to a NV Media Card file xxx
16xxx Transfer the user program in an option module installed in slot 2 to a NV Media Card file xxx
17xxx Transfer the user program in an option module installed in slot 3 to a NV Media Card file xxx
18xxx Transfer the user program from file xxx in a NV Media Card to an option module installed in slot 1.
19xxx Transfer the user program from file xxx in a NV Media Card to an option module installed in slot 2.
20xxx Transfer the user program from file xxx in a NV Media Card to an option module installed in slot 3.
21xxx Transfer the user program in an option module installed in slot 4 to a NV Media Card file xxx.
22xxx Transfer the user program from file xxx in a NV Media Card to an option module installed in slot 4.
