6 Installing and Replacing Other Components

82 IP390, 105i & 105s Security Platform Installation Guide

5. Insert the hard-disk drive unit.

Note

Push the hard-disk drive gently into place. Take care to align the

connectors correctly as the connectors are not keyed.

00536
