Nokia N72

12. Check that the tuning values are within the limits specified in the following table:
Min Typ Max Unit
GSM900
Ch. 965 /
923.26771
MHz
-10 -1 5 dB
Ch. 975 /
925.26771
MHz
-3 0 5 dB
Ch. 987 /
927.66771
MHz
-3 0 5 dB
Ch. 1009 /
932.06771
MHz
-3 0 5 dB
Ch. 37 /
942.46771
MHz
-3 0 5 dB
Ch. 90 /
953.06771
MHz
-3 0 5 dB
Ch. 114 /
957.86771
MHz
-3 0 5 dB
Ch. 124 /
959.86771
MHz
-3 0 5 dB
Ch. 136 /
962.26771
MHz
-10 -1 5 dB
GSM1800
Ch. 497 /
1802.26771
MHz
-10 -1 5 dB
Ch. 512 /
1805.26771
MHz
-3 0 5 dB
Ch. 535 /
1809.86771
MHz
-3 0 5 dB
Ch. 606 /
1824.06771
MHz
-3 0 5 dB
RM-180
RF Troubleshooting and Tuning Guide Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 7 –25
Copyright © 2006 Nokia. All rights reserved.
