Nokia N72

Item Side Grid ref. Type Description and value
C3005 Top I 1 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C3006 Top I 2 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C3007 Top H 1 0402C
Chipcap X7R 10% 16V
0402 10n 16V
C3008 Top I 2 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C4200 Top D 2 0805C
CHIPCAP X5R 22U M
6V3 0805 22u 6V3
C4201 Top D 1 0805C
CHIPCAP X5R 22U M
6V3 0805 22u 6V3
C4203 Top B 2 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C4204 Top C 2 0402C Chipcap 5% NP0 100p 50V
C4205 Top B 5 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C4206 Top B 1 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C4400 Top D 19 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C4401 Top D 19 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C4402 Top D 19 0402C Chipcap 5% NP0 27p 50V
C4800 Top D 4 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C4801 Top E 2 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C4802 Top G 5 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C4803 Top G 5 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C4804 Top E 5 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C4805 Top G 3 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C4806 Top E 3 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C4807 Top D 4 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
RM-180
Nokia Customer Care Parts Lists and Component Layouts
Page 2 –14 COMPANY CONFIDENTIAL Issue 1
Copyright © 2006 Nokia. All rights reserved.
