Nokia N72

Item Side Grid ref. Type Description and value
C4808 Top G 3 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C4809 Top G 4 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C4810 Top F 3 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C4811 Top E 3 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C4812 Top E 5 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C4813 Top G 4 0402C
Chipcap X7R 10% 50V
0402 1n0 50V
C4814 Top E 6 0402C Chipcap 5% NP0 22p 50V
C5000 Top B 2 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C5001 Top D 3 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C5002 Top D 4 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C5003 Top B 2 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C5004 Top D 3 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C5005 Top D 5 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C5200 Bot H 7 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C7501 Bot C 11 0402C Chipcap 5% NP0 18p 50V
C7503 Bot C 11 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C7504 Bot C 11 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C7505 Bot B 11 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C7507 Bot C 10 0402C Chipcap 5% NP0 18p 50V
C7508 Bot B 10 0402C Chipcap 5% NP0 18p 50V
C7509 Bot C 11 0402C Chipcap +-0.25pF NP0 2p7 50V
C7512 Bot G 19 0402C Chipcap 5% NP0 39p 50V
C7513 Bot B 11 0402C
Chipcap X7R 10% 25V
0402 4n7 25V
