Nokia N72

Item Side Grid ref. Type Description and value
C7514 Bot G 19 0402C Chipcap 5% NP0 39p 50V
C7515 Bot C 9 0402C Chipcap 5% NP0 10p 50V
C7516 Bot C 9 0402C Chipcap 5% NP0 150p 50V
C7518 Bot E 9 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C7520 Bot C 11 0402C Chipcap 5% NP0 18p 50V
C7522 Bot C 9 0402C Chipcap 5% NP0 150p 50V
C7523 Bot G 18 0402C Chipcap +-0.25pF NP0 5p6 50V
C7524 Bot B 9 0603C
CHIPCAP NP0 2N2 G
16V 0603 2n2 16V
C7525 Bot G 18 0402C Chipcap +-0.25pF NP0 5p6 50V
C7527 Bot B 10 0402C Chipcap 5% NP0 100p 50V
C7528 Bot B 10 0402C Chipcap 5% NP0 22p 50V
C7529 Bot D 9 0402C Chipcap 5% NP0 100p 50V
C7530 Bot B 11 0402C
Chipcap X7R 10% 16V
0402 8n2 16V
C7531 Bot C 10 0402C Chipcap 5% NP0 22p 50V
C7532 Bot B 11 0402C
Chipcap X7R 10% 16V
0402 8n2 16V
C7533 Bot C 8 0402C
CERCAP X7R 22N K 16V
0402 22n 16V
C7534 Bot B 11 0402C
Chipcap X7R 10% 16V
0402 8n2 16V
C7536 Bot B 11 0402C
Chipcap X7R 10% 16V
0402 8n2 16V
C7541 Bot D 9 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C7543 Bot E 10 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C7545 Bot I 17 0402C Chipcap +-0.25pF NP0 4p7 50V
C7547 Bot D 9 0402C Chipcap +-0.25pF NP0 1p8 50V
C7548 Bot D 8 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C7549 Bot D 9 0402C Chipcap 5% NP0 100p 50V
C7550 Bot E 8 0402C Chipcap +-0.25pF NP0 2p7 50V
C7552 Bot D 8 0402C Chipcap +-0.25pF NP0 2p7 50V
C7553 Bot D 8 0402C
Chipcap X7R 10% 16V
0402 8n2 16V
RM-180
Nokia Customer Care Parts Lists and Component Layouts
Page 2 –16 COMPANY CONFIDENTIAL Issue 1
Copyright © 2006 Nokia. All rights reserved.
