Nokia N72

Item Side Grid ref. Type Description and value
C7554 Bot B 6 0402C Chipcap +-0.25pF NP0 4p7 50V
C7555 Bot B 6 0402C
CHIPCAP NP0 0P5 C 50V
0402 0p5 50V
C7556 Bot G 16 0402C Chipcap 5% NP0 10p 50V
C7558 Bot E 10 0402C Chipcap 5% X7R 1n0 50V
C7559 Bot I 18 0402C Chipcap +-0.25pF NP0 1p0 50V
C7560 Bot E 9 0402C
Chipcap X7R 10% 25V
0402 4n7 25V
C7561 Bot G 17 0402C Chipcap +-0.25pF NP0 4p7 50V
C7563 Bot G 17 0402C Chipcap +-0.25pF NP0 4p7 50V
C7564 Bot H 18 0402C Chipcap 5% X7R 1n0 50V
C7567 Bot E 10 0402C Chipcap 5% NP0 15p 50V
C7568 Bot E 8 0402C Chipcap 5% NP0 150p 50V
C7569 Bot G 17 0603C
CHIPCAP X5R 4U7 K 6V3
0603 4u7 6.3V
C7570 Bot E 9 0402C Chipcap 5% NP0 18p 50V
C7571 Bot B 6 0402C
CHIPCAP NP0 330P J
50V 0402 330p 50V
C7573 Bot A 6 0603C
CHIPCAP NP0 2N2 G
16V 0603 2n2 16V
C7575 Bot E 10 0402C Chipcap 5% NP0 15p 50V
C7577 Bot E 10 0402C Chipcap 5% NP0 15p 50V
C7581 Bot G 19 0402C Chipcap 5% NP0 39p 50V
C7582 Bot D 9 0402C Chipcap 5% NP0 100p 50V
C7584 Bot G 18 0402C Chipcap 5% NP0 39p 50V
C7593 Bot G 16 0603C
CHIPCAP X5R 4U7 K 6V3
0603 4u7 6.3V
C7596 Bot C 11 0402C Chipcap +-0.25pF NP0 2p7 50V
C7597 Bot F 14
TANT_6.3X3.5_
H2.0
CHIPTCAP 100U M 14V
6X3.2X2 100u_14V 14V
C7598 Bot B 8 0402C
CHIPCAP NP0 0P5 C 50V
0402 0p5 50V
C7599 Top D 20 0402C
CHIPCAP X7R 33N K
10V 0402 33n 10V
C7600 Top B 20 0603C
CHIPCAP X5R 2U2 K 6V3
0603 2u2 6V3
C7601 Top B 20 0603C
CHIPCAP X5R 2U2 K 6V3
0603 2u2 6V3
RM-180
