Nokia N72

Item Side Grid ref. Type Description and value
C7602 Top B 2 0402C Chipcap 5% NP0 12p 50V
C7604 Bot F 3 0402C
CHIPCAP X5R 100N K
10V 0402 100n 10V
C7605 Bot F 3 0402C
CHIPCAP X5R 100N K
10V 0402 100n 10V
C7606 Bot H 2 0402C Chipcap 5% NP0 10p 50V
C7607 Bot H 2 0402C Chipcap 5% NP0 10p 50V
C7608 Bot H 2 0402C Chipcap 5% NP0 10p 50V
C7609 Bot G 2 0402C Chipcap 5% NP0 10p 50V
C7612 Bot C 4 0402C
CHIPCAP X5R 100N K
10V 0402 100n 10V
C7613 Bot F 3 0402C
CHIPCAP X5R 100N K
10V 0402 100n 10V
C7615 Bot C 9 0402C Chipcap +-0.25pF NP0 4p7 50V
C7616 Bot F 3 0402C
Chipcap X7R 10% 16V
0402 10n 16V
C7617 Bot F 3 0402C Chipcap 5% NP0 100p 50V
C7618 Bot F 3 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
D2800 Top H 4 uBGA_289
RAP V2.21E-PA C027
UBGA ~ ~
D3000 Top H 7
PBFREEBGA40_
64MB_54MHZ_
MAX
FLASH 4MX16 1.8/1.8V
VFBGA44 PBFREE 4MX16 ~
D3001 Top H 2
WBGA_60_8.1X
6.6_H0.9
SDRAM 4MX16 1.8V/
1.8V WBGA60 4Mx16 ~
D4800 Top E 4 uBGA_289
HELEN3 PS1.1E
F761991A C027
UBGA289 ~ ~
D5000 Top B 4 FBGA133
COMBO 512 DDR +
512M NAND FBGA133
PBFREE
32Mx16/6
4Mx8 ~
D5001 Bot D 4
LGA_BTHFM_ES
3.6
BTHFM1.0_ES3.6
MODULE ~ ~
F2000 Bot C 2
0603_FUSE_AV
X2MATS SM FUSE F 2.0A 32V 2A ~
G2200 Top F 6
BATTER_RB414
H
RTC CAPACITOR 15UAH
2.6/3.3V 414-SIZE 3V3 ~
G7500 Bot B 9
VCO_FDK_WB0
02
VCO 3610-4340MHZ
2.7V 15MA
3610-434
0MHz ~
RM-180
