Nokia N72

Item Side Grid ref. Type Description and value
G7501 Bot C 9
NKG3176B_H1.
0
VCTCXO 38.4MHZ 2.5V
2MA 38.4MHz ~
G7502 Bot B 7
VCO_FDK_WB0
02
VCO 3296-3980MHZ
2.7V 20MA EGSM
3296-398
0MHz ~
L1473 Bot E 11 CHOKE_SER300
CHOKE 3.3UH 0R252
0A82 310 CASE SIZE 3u3H ~
L1474 Top E 7 0805_BLM21
FERR.BEAD 0R03 42R/
100MHZ 3A 0805
42R/
100MHz ~
L1479 Bot C 15 0402L
CHIP COIL 27N J
Q27/800M 0402 27nH ~
L1480 Bot C 15 0402L
CHIP COIL 27N J
Q27/800M 0402 27nH ~
L2000 Bot C 2 0603_BLM
FERR.BEAD 220R/100M
2A 0R05 0603
220R/
100MHz ~
L2001 Bot F 2
0405_2_MATS
U
CHIP BEAD ARRAY
2X1000R 0405
2x1000R/
100MHz ~
L2002 Bot G 2
0405_2_MATS
U
CHIP BEAD ARRAY
2X1000R 0405
2x1000R/
100MHz ~
L2003 Bot G 2
0405_2_MATS
U
CHIP BEAD ARRAY
2X1000R 0405
2x1000R/
100MHz ~
L2100 Top E 19
0405_2_MATS
U
CHIP BEAD ARRAY
2X1000R 0405
2x1000R/
100MHz ~
L2101 Top B 6 0603_BLM
FERR.BEAD 220R/100M
2A 0R05 0603
220R/
100MHz ~
L2102 Bot F 18 COIL_0603CS
CHIP COIL 56N J
Q38/250MHZ 0603 56nH ~
L2103 Bot F 18 COIL_0603CS
CHIP COIL 56N J
Q38/250MHZ 0603 56nH ~
L2104 Top B 6 0603_BLM
FERR.BEAD 220R/100M
2A 0R05 0603
220R/
100MHz ~
L2105 Top B 6 0402L_XL
FERRITE BEAD 220R
0R45 0.3A 0402
220R/
100MHz ~
L2106 Top A 6 0402L_XL
FERRITE BEAD 220R
0R45 0.3A 0402
220R/
100MHz ~
L2202 Top E 7 0603_BLM
FERR.BEAD 220R/100M
2A 0R05 0603
220R/
100MHz ~
L2203 Top C 7 FERRITE_0402
FERRITE BEAD 0.6R
600R/100MHZ 0402
600R/
100MHz ~
L2204 Top D 7 FERRITE_0402
FERRITE BEAD 0.6R
600R/100MHZ 0402
600R/
100MHz ~
RM-180
Parts Lists and Component Layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –19
Copyright © 2006 Nokia. All rights reserved.
