Nokia N72

Item Side Grid ref. Type Description and value
L2205 Top B 5 0603_BLM
FERR.BEAD 220R/100M
2A 0R05 0603
220R/
100MHz ~
L2206 Top B 7 FERRITE_0402
FERRITE BEAD 0.6R
600R/100MHZ 0402
600R/
100MHz ~
L2301 Bot E 6 0603_BLM
FERR.BEAD 220R/100M
2A 0R05 0603
220R/
100MHz ~
L2302 Bot D 5 CHOKE_SER400
CHOKE 10U 0.8A 0R24
4X4X1.8 10uH ~
L2304 Top G 7
CHOKE_SER300
_H1.5
CHOKE 22U M 0R7
0.35A 3.0x3.0x1.5 22uH ~
L4200 Top C 2 CHOKE_SER400
CHOKE 10U 0.8A 0R24
4X4X1.8 10uH ~
L4201 Top E 2 0603_BLM
FERR.BEAD 220R/100M
2A 0R05 0603
220R/
100MHz ~
L4400 Top D 19 FERRITE_0402
FERRITE BEAD 0.6R
600R/100MHZ 0402
600R/
100MHz ~
L4401 Top D 19 FERRITE_0402
FERRITE BEAD 0.6R
600R/100MHZ 0402
600R/
100MHz ~
L5200 Bot H 7 FERRITE_0402
FERRITE BEAD 0.6R
600R/100MHZ 0402
600R/
100MHz ~
L7502 Bot D 8 0402L
CHIP COIL 100N J
Q16/300M 0402 100nH ~
L7503 Bot E 10 FERRITE_0402
FERRITE BEAD 0.6R
600R/100MHZ 0402
600R/
100MHz ~
L7504 Bot H 19 0402L
CHIP COIL 47N J
Q23/800MHZ 0402 47nH ~
L7506 Bot H 18 0402L
CHIP COIL 12N J
Q31/800M 0402 12nH ~
L7516 Bot G 16 FERRITE_0402
FERRITE BEAD 0.6R
600R/100MHZ 0402
600R/
100MHz ~
L7517 Bot E 8 0402L
CHIP COIL 1N5 +-0N3
Q33/800M 0402 1n5H ~
L7518 Bot G 3 COIL_LK_1608
CHIP COIL 68NH J
Q12/100MHZ 0603 68nH ~
N1470 Bot G 7 LLP6
REG LP3990YDX-1.5V
LLP-6 ~ 1.5V
N1471 Bot E 13 SON3024_8
STEP-UP DC/DC CONV
SON3024-8 ~ ~
N1472 Bot E 14
USMD5_1.47X1
.04_H0.675
VREG LP3985ITLX-2.8
NOPB USMD5 ~ 3V
RM-180
Nokia Customer Care Parts Lists and Component Layouts
Page 2 –20 COMPANY CONFIDENTIAL Issue 1
Copyright © 2006 Nokia. All rights reserved.
