Nokia N72

Item Side Grid ref. Type Description and value
N1474 Top D 20 TFBGA_42
14XLEVEL SHIFTER
ST16C32245TBR
uTFBGA42 ~ ~
N2200 Top C 6 TFBGA_108
RETU 3.02 TSA1GJWE
TFBGA108 ~ ~
N2300 Bot D 7
TFBGA_84_6.1
5X6.15
TAHVO V5.2 LF
TFBGA84 ~ ~
N2301 Top G 6
USMD8_1.69X1
.69
WHITE LED DRIVER
4LEDS 500MW 8BUMP
USMD8 ~ ~
N4200 Top D 1
USMD_10_2.45
8X1.899
DC/DC CONV
LM3661-1.40V/1.05V
NOPB ~ ~
N4201 Top B 2
USMD5_1.468X
1.036
REG+ LP3999ITLX 1.8V
150MA NOPB ~ 1.8V
N7500 Bot C 11
TFBGA_84_6.1
5X6.15
RF ASIC HINKU310A
TFBGA84 ~ ~
N7501 Bot E 9 TFBGA64_H1.2
RF ASIC VINKU314A
TFBGA64 ~ ~
N7502 Bot H 17 RITSA_PA_REL3
PW AMP RF9292E9.2
QUADBAND ~ ~
N7505 Top C 20 LLP_6
REG LP3981YDX 2.8/
NOPB 0.3A LLP-6 ~ 2.8V
R1470 Top G 4 0402R Resistor 5% 63mW 100R ~
R1471 Top G 4 0402R Resistor 5% 63mW 100R ~
R1472 Top F 3 0402R Resistor 5% 63mW 3k3 ~
R1473 Top F 3 0402R Resistor 5% 63mW 3k3 ~
R1474 Top G 5 0402R Resistor 5% 63mW 33R ~
R1475 Bot F 7 0402R Resistor 5% 63mW 470k ~
R1486 Top E 20 0402R Resistor 5% 63mW 15R ~
R1487 Bot E 12 0402R
CHIPRES 0W06 6R8 J
0402 6R8 ~
R1488 Top D 19 0402R Resistor 5% 63mW 33R ~
R1489 Bot E 13 0402R Resistor 5% 63mW 3k3 ~
R1490 Top E 20 0402R
Chipres 0W06 jumper
0402 0R ~
R1491 Bot E 12 0402R Resistor 5% 63mW 10k ~
R2000 Bot F 3 0402R Resistor 5% 63mW 220R ~
R2001 Bot F 3
uBGA11_2.15X
1.65
ASIP MIC W/ESD RES
+CAP+ZDI BGA11 ~ ~
RM-180
