Item Side Grid ref. Type Description and value
R2002 Bot G 3 0402R Resistor 5% 63mW 10R ~
R2003 Bot G 3 0402R Resistor 5% 63mW 10R ~
R2004 Bot G 3 0402R Resistor 5% 63mW 10R ~
R2005 Bot H 3 0402R Resistor 5% 63mW 10R ~
R2006 Bot G 2 uBGA5
ASIP 4XESD **PB-
FREE** BGA5 ~ ~
R2007 Top F 1
uBGA11_1.6X2
.15
ASIP SILIC USB OTG /
ESD BGA11 ~ ~
R2009 Top G 1 0402R Resistor 5% 63mW 100R ~
R2010 Top F 1 0402R Resistor 5% 63mW 220k ~
R2011 Top G 1 0402R Resistor 5% 63mW 120k ~
R2070 Bot G 14 0402_VAR
CHIP VARISTOR
VWM14V VC50V 0402 14V/50V ~
R2071 Top E 6 0402_NTH5
NTC RES 47K J B=4050
+-3% 0402 47k ~
R2100 Bot F 2
FLIP_CHIP_8_1.
7X1.7
ASIP SINGLE ENDED
MICROPHONE INTERF
BGA8 ~ ~
R2101 Bot E 2 0402R Resistor 5% 63mW 220R ~
R2104 Top E 19 0402_VAR
CHIP VARISTOR
VWM14V VC50V 0402 14V/50V ~
R2105 Top E 19 0402_VAR
CHIP VARISTOR
VWM14V VC50V 0402 14V/50V ~
R2106 Bot F 18 0402_VAR
CHIP VARISTOR
VWM14V VC50V 0402 14V/50V ~
R2107 Bot F 18 0402_VAR
CHIP VARISTOR
VWM14V VC50V 0402 14V/50V ~
R2200 Top E 6 0402R Resistor 5% 63mW 100k ~
R2201 Top E 6 0402R Resistor 5% 63mW 120k ~
R2202 Top E 6 0402R Resistor 5% 63mW 100R ~
R2205 Top E 7 0402R
CHIPRES 0W06 2M2 J
0402 2M2 ~
R2303 Top F 6 0402R
Chipres 0W06 jumper
0402 0R ~
R2304 Top F 6 0402R Resistor 5% 63mW 33R ~
R2305 Bot C 7 0402R Resistor 5% 63mW 33R ~
R2700 Bot I 6
uBGA8_1.47X1
.47
ASIP SIM INTERFACE
**LOW CAP**BGA8 ~ ~
R3000 Top G 6 0402R Resistor 5% 63mW 10k ~
