Nokia N72

Item Side Grid ref. Type Description and value
R4400 Top E 6 0402R Resistor 5% 63mW 470k ~
R4401 Top E 6 0402R Resistor 5% 63mW 100k ~
R4402 Top E 6 0402R Resistor 5% 63mW 470k ~
R4403 Top B 20 0402_NTH5
NTC RES 47K J B=4050
+-3% 0402 47k ~
R4406 Top E 20 0402_VAR
CHIP VARISTOR
VWM14V VC50V 0402 14V/50V ~
R4407 Bot A 8 0402_VAR
CHIP VARISTOR
VWM14V VC50V 0402 14V/50V ~
R4408 Bot A 8 0402R Resistor 5% 63mW 10k ~
R4800 Top D 5 0402R Resistor 5% 63mW 10R ~
R4809 Top E 3 0402R Resistor 5% 63mW 1k0 ~
R4810 Top E 6 0402R Resistor 5% 63mW 15R ~
R5100 Top G 5 0402R Resistor 5% 63mW 10k ~
R5200 Bot I 7
uBGA11_1.62X
2.12
ASIP EMIF04-
MMC02F2**PB-FREE** ~ ~
R5204 Bot I 15 0402_VAR
CHIP VARISTOR
VWM14V VC50V 0402 14V/50V ~
R7501 Bot C 9 0402R Resistor 5% 63mW 1k0 ~
R7503 Bot C 11 0402R Resistor 5% 63mW 4k7 ~
R7504 Bot C 11 0402R
CHIPRES 0W06 10K F
0402 10k ~
R7505 Bot C 9 0402R
CHIPRES 0W06 8K2 F
0402 8k2 ~
R7506 Bot G 17 0402R Resistor 5% 63mW 33R ~
R7509 Bot C 8 0402R Resistor 5% 63mW 10k ~
R7512 Bot H 16 0404_RAC10
RES NETWORK 0W04
2DB ATT 0404
436R/
11R6/436
R ~
R7513 Bot B 7 0402R
Chipres 0W06 5R6 J
0402 5R6 ~
R7514 Bot D 9 0402R Resistor 5% 63mW 10k ~
R7516 Bot I 18 0402R Resistor 5% 63mW 1k0 ~
R7518 Bot I 17 0402R Resistor 5% 63mW 470k ~
R7519 Bot B 6 0402R Resistor 5% 63mW 1k0 ~
R7521 Bot D 9 0402R
CHIPRES 0W06 10K F
0402 10k ~
R7523 Bot A 6 0402R
CHIPRES 0W06 9K1 F
100PPM 0402 9k1 ~
