Nokia N72

Item Side Grid ref. Type Description and value
R7528 Bot C 8 0402R Resistor 5% 63mW 470k ~
R7534 Bot C 8 0402R Resistor 5% 63mW 470k ~
R7541 Bot F 4 0402R
Chipres 0W06 jumper
0402 0R ~
R7542 Bot F 4 0402R
Chipres 0W06 jumper
0402 0R ~
R7543 Bot F 4 0402R
Chipres 0W06 jumper
0402 0R ~
R7544 Bot F 5 0402R
Chipres 0W06 jumper
0402 0R ~
R7549 Bot F 4 0402R Resistor 5% 63mW 3k3 ~
R7550 Bot F 4 0402R Resistor 5% 63mW 3k3 ~
R7551 Bot C 4 0402R
Chipres 0W06 jumper
0402 0R ~
R7552 Bot F 5 0402R
Chipres 0W06 jumper
0402 0R ~
R7554 Top G 3 0402R Resistor 5% 63mW 100k ~
R7555 Bot B 9 0402R Resistor 5% 63mW 220R ~
R7556 Bot E 6 0402R Resistor 5% 63mW 100R ~
R7558 Bot F 3 0402R Resistor 5% 63mW 220R ~
R7559 Bot G 2 0402_VAR
RES VARISTOR 14/90V
3PF 0402 14/90V ~
R7560 Bot A 17 0402R
Chipres 0W06 jumper
0402 0R ~
S4401 Top E 21
SWITCH_EVQP
7A01K
SM SW TACT SPST 12V
SIDE KEY 2.2N ~ ~
S5200 Bot I 14
SWITCH_SPVN
220100
SM SW DETECTOR SPST-
NO 5V 1MA ~ ~
S5202 Bot A 9
SWITCH_SPVM
110201
SWITCH DETECTOR
SPVM ~ ~
T7501 Bot B 10 TRANS_LDB15
TRANSF BALUN 3800
+-550MHZ 0805 ~ ~
T7502 Bot H 16 TRANS_LDB15
TRANSF BALUN 1800
+-100mhz 2x1.25 ~ ~
T7503 Bot B 7 TRANS_LDB15
TRANSF BALUN 3800
+-550MHZ 0805 ~ ~
V1470 Bot F 14 SC_89
DI SCH DUAL 0.4V 1MA
SOT490 ~ ~
V1471 Bot E 13
DIODE_PMEG3
002
SCH DI PMEG3002 30V
500MA SOD882 ~ ~
RM-180
Nokia Customer Care Parts Lists and Component Layouts
Page 2 –24 COMPANY CONFIDENTIAL Issue 1
Copyright © 2006 Nokia. All rights reserved.
