Nokia N72

Item Side Grid ref. Type Description and value
V1472 Bot E 12 SC_75A_H0.95
MOSFET N 20V 350MA
SOT416 ~ ~
V2000 Bot C 3
BGA4_1.01X1.
07 ASIP TVS BGA4 ~ ~
V2300 Bot C 7 VMT3_R
TR DTC143ZM N
RB=4K7 RBE=47K
VMT3 ~ ~
V4400 Top B 20 PT202MR0MP
DI PHOTO
PT202MR0MP 620NM
1.25X2 ~ ~
V7501 Bot E 6 SOD323F SCH DI 30V 2A SOD323F ~ ~
V7502 Bot C 15 SOD882 BZX884-AA ~ ~
X1470 Bot E 16
SOCKET_DMD1
0413
CAMERA MOD.SOCKET
2X7POL SPR P1.4 ~ ~
X2001 Bot F 1
SYSCON_MQ20
2_NK_14R3
SM SYSTEM
CONNECTOR 14POL ~ ~
X2060 Top A 9
TRACEABILITY_
PAD
MODULE ID
COMPONENT
2.8X1.8X0.3 ~ ~
X2070 Bot H 14
LYNX_BATT_CO
NN_H7.0
SM BATTERY CONN
3POL SPR 12V 2A ~ ~
X2700 Bot H 6
SIM_CONN_470
191501
SM SIM CONN 6POL
P2.54 H1.5 ~ ~
X4400 Top F 2
SMK_4309_B_B
_16P_V8
SM CONN 16P SPR P1.3
50V PWB/PWB ~ ~
X4401 Top B 19
JST_R_JAVK_G_
1_R3
SM CONN 2X12F P0.4
30V .3A PWB/PWB ~ ~
X5200 Bot H 11
MOLEX_MMC_P
03_3D0545_00
1
CONN SMC RS-MMC
6POL P2.5 ~ ~
X5207 Bot H 4
ANT_CLIP_M3E
14601
SPRING CLIP
M3E14601 NSJ-3
HD925 ~ ~
X5208 Bot B 5
CONTACT_PAD_
2.95X1.95
SM CONN VIBRA
SPACER PAD 2.8X1.8 ~ ~
X5209 Bot B 4
CONTACT_PAD_
2.95X1.95
SM CONN VIBRA
SPACER PAD 2.8X1.8 ~ ~
X5210 Bot A 4
CONTACT_PAD_
2.95X1.95
SM CONN VIBRA
SPACER PAD 2.8X1.8 ~ ~
X5211 Bot A 5
CONTACT_PAD_
2.95X1.95
SM CONN VIBRA
SPACER PAD 2.8X1.8 ~ ~
