Nokia N72

Item Side Grid ref. Type Description and value
X5212 Bot C 16
POGO_CNO_51
17_3077H
CONN 2POL SPR
6.6X6.8X2.5 ~ ~
Z2000 Top E 1 FERRITE_0402
FERRITE BEAD 0.6R
600R/100MHZ 0402
600R/
100MHz ~
Z2001 Top E 1 FERRITE_0402
FERRITE BEAD 0.6R
600R/100MHZ 0402
600R/
100MHz ~
Z2003 Top E 1 FERRITE_0402
FERRITE BEAD 0.6R
600R/100MHZ 0402
600R/
100MHz ~
Z4400 Top D 2
uBGA25_2.47X
2.47
ASIP 10-CH ESD EMI
FILTER BGA25 ~ ~
Z4401 Top G 3 FC6_1.65X1.15
ASIP 2-CH MIC EMI/ESD
**PB-FREE** ~ ~
Z4402 Top E 7
uBGA25_2.47X
2.47
ASIP 10-CH ESD EMI
FILTER BGA25 ~ ~
Z4403 Top F 7
uBGA25_2.47X
2.47
ASIP 10-CH ESD EMI
FILTER BGA25 ~ ~
Z7500 Bot F 14
FERRITE_FBMJ1
608
FERRITE BEAD 0R01
28R/100MHZ 0603
28R/
100MHz ~
Z7503 Bot H 18
ANT_SW_M043
B
ANT.SW+3SAW
880-960/1710-1990M
HZ ~ ~
Z7504 Bot I 16
FILTER_SAW_2.
1X1.7_H0.8
SAW FILTER 897.5
+-17.5MHZ 2.0X1.6 897.5MHz ~
RM-180
